Side wall height 500 mm with 2.5 mm thickness, hot-dip galvanized
Central side wall locking (lower side boards)
External ladder and steps inside the load box hot-dip galvanized, with anti-slip steps facilitating access to the load box
Axles from the renowned company ADR
Two wheel chocks placed in galvanized pockets
Hydraulic drawbar support
New tires 400/60-15.5
Technical data
- Gross vehicle weight rating (kg): DMC 8500
- Gross vehicle weight rating (kg):Registered in CoC 7500
- Max. drawbar load (kg) 1000
- Kerb weight (kg) Wheels 400/60-15,5, without extensions ~2060
- Kerb weight (kg) Wheels 500/50-17, extensions 500 2300
- Loading capacity* Wheels 400/60-15,5 without extensions ~6440
- Loading capacity* Wheels 500/50-17, extensions 500 6200
- Maximum speed (km/h): 30
- Power demand (KW/KM): 45/50
- Cargo box dimensions D_x_Sz_X_W – trapezoidal box (mm) 4020/2070/2120 (front/back) x 500
- Loading surface (m2) 8,4
Standard tires: 400/60-15.5 min 154 A6 (150 A8)
Tires option: 500/50-17 min 154 A6 (150 A8)
Number of axles: 1
Suspension: Rigid
Total length [mm] ~ 5575
Total width [mm] ~ 2300
Total height [mm] without extensions ~ 1700
Total height [mm] with 500 extensions ~ 2200
Total height [mm] with 500 extensions and tarpaulin ~ 2400
Floor height above the ground [mm] ~ 1200
Floor/wall sheet thickness 4 / 2.5
Track of wheels 1600
Drawbar coupling height – bottom position ~ 600
Drawbar coupling height – top position ~ 930
Drawbar coupling height – overrun brake ~ 820
Tipping angle of the cargo box (backward / sideways) 45/50
Downloads
Features and accessories
- Wall height 500 mm, thickness 2.5 mm, hot-dip galvanised
- Central locking of walls (lower boards)
- External ladder and internal steps in the cargo box, hot-dip galvanised, with anti-slip treads for easier access
- Hot-dip galvanised service support for the cargo box
- Rigid drawbar for connection to the tractor’s lower or upper hitch with a replaceable eye, homologated in accordance with Regulation 55 UN ECE
- Bolted hitch link diameter 40 mm
- Cargo box frame hot-dip galvanised
- Main longitudinal members of the cargo box frame made of 160 rolled steel channels
- Galvanised cargo box floor made from a single 4 mm thick sheet, bolted and riveted
- Lower frame hot-dip galvanised (profiles protected inside and outside), longitudinal members made of 160x80x8 rectangular profiles
- Parking handbrake with crank
- Hot-dip galvanised grain discharge slider with a lock in the rear wall
- Mechanical support with crank
- Homologated hot-dip galvanised bumper
- Tension straps for securing walls
- Tipping system secured by a shut-off valve to prevent excessive tilting of the box
- Lighting installation cable with 7PIN 12V plug
- 12V lighting homologated, rear bulb lamps, LED outline illumination
- Hydraulic tipping system of the cargo box made of galvanically zinc-coated steel pipes and flexible hoses
- Hydraulic connection to the tractor ISO 7241-1 DN 12.5
- Homologated pneumatic two-line brake system with manual brake force adjustment
- Rear hydraulic, electric, and brake outputs for a second trailer
- New wheels 400/60-15.5
- Axles from the renowned ADR company, full square beam cross-section 80 mm, brake 300×90
- Two wheel chocks stored in galvanised pockets
- Four-stage telescopic cylinder with articulated suspension, stroke 1300 mm, effective force on the fourth stage diameter 105 mm, nominal pressure 16 MPa = 138 kN (~14T)
Additional equipment
- Hot-galvanized tarpaulin frame made of 40x40x3 closed profi les
- Hot-galvanized 500 mm wall extensions, thickness 2.5mm
- Rear hitch for second trailer
- Chute for precise tipping, hot-galvanized
- Hot-galvanized work platform
- Full LED lighting
- Overrun braking system
- Tires 500/50-17
- 400/60-15.5 spare wheel, standalone
- 500/50-17 spare wheel, standalone
- Drawbar eye 40mm
- Roll-up tarpaulin
- Laced tarpaulin
- Warning triangle (sign distinguishing slow-moving vehicle)
- Hydraulic quick-coupler with pressure neutralizer in hose
- Set of side (bicycle) guards
- DUPLEX – painted set of walls
- DUPLEX – painted set of extensions
- Hydraulic drawbar support
