Wall height 1000 mm with thickness 4mm
Exterior ladder and steps inside cargo box - hot-galvanized - with anti-skid steps facilitating access
to cargo box
to cargo box
Hot-galvanized drawbar with exchangeable eye, rubber shock absorbers, homologated
Hydraulic drawbar support with built-in hydraulic lock
Inspection window in front wall, extension
Rear wall opened hydraulically
New 385/65 R22.5 wheels
Axles from renowned ADR company, full beam with 100 mm square cross-section, 406 x 120 brake
Technical data
- Administrative loading capacity ~ 12,140 kg*
- Technical loading capacity ~ 16,300 kg*
- Gross vehicle weight rating according to PL regulations 17,540 kg
- Gross vehicle weight rating according to
Directive 2015/208 (only load on axles) 14,540 kg - Kerb weight (without wall extensions) ~5400 kg*
- Number of axles 2 (tandem)
- Length 7645 mm
- Width 2,550 mm
- Height without extensions ~2,380 mm
- Height with extensions ~2,880 mm
- Box type Shell, not pallet type
* – unladen weight and loading capacity may differ depending on the trailer’s equipment
- Length of cargo box interior 6,020 mm
- Width of cargo box interior front/rear 2,200 mm
- Height of box walls (without extensions) 1,000 mm
- Height of platform from base ~1,380 mm
- Floor/wall sheet thickness 5 / 4 mm
- Loading surface 12.9 m2
- Loading capacity – without extensions (with
extensions) 13.1 m3 (19.7 m3) - Track of wheels 1,900 mm
- Wheelbase 1,480 mm
- Suspension parabolic springs
- Max. vertical drawbar eye load 3,000 kg (4,000 kg with K80 tension member)
- Max dopuszczalne pionowe obciążenie osi 1. 7 270 kg 2. 7 270 kg
- Max. tolerable vertical load on axle 1. 7270 kg 2. 7,270 kg
- Tire size 385/65 R22.5
- Design speed 40 km/h
- Minimum demand for tractor power 81 kW / 110 HP
- Tipping angle of the cargo box (backward /
sideways) — / 45 - Tipping system rear chute
Downloads
Features and accessories
- Wall height 1000 mm with thickness 4mm
- Hooks securing the rear wall
- Exterior ladder and steps inside cargo box – hot-galvanized – with anti-skid steps facilitating access
to cargo box - Maintenance support of cargo box, hot-galvanized
- Hot-galvanized drawbar with exchangeable eye, rubber shock absorbers, homologated
- Bolted hitch tension member dia. 50
- Cargo box frame painted in two steps (prime coat/topcoat) with high-grade paints
- Shell cargo box made of 4mm sheets (walls) and 5mm sheets (floor). Main stringers of cargo box made of 150x150x8 closed profiles
- Floor made of single sheet, thickness 5mm
- Hot-dip galvanized bottom frame (protection of the structure on the exterior and interior of profiles),
stringers of the frame made of 250x150x8 closed sections - Parking handbrake with crank
- Grain chute, hot-galvanized, with blockade in the rear wall
- Hydraulic drawbar support with built-in hydraulic lock
- Homologated, hot-galvanized bumper
- Inspection window in front wall, extension
- Rear wall opened hydraulically
- Tipping installation protected against excessive box inclination by cut-off valve
- Lighting installation connector cable with 7PIN 12V plug
- 12V lighting, homologated, rear bulb lamps, LED perimeter lighting
- Hydraulic installations made of galvanized steel tubes and flexible hoses
- Hydraulic connectors to tractor, type ISO 7241-1 DN 12.5
- Pneumatic, double-circuit brake installation with output for second trailer
- Rear hydraulic, electrical and brake output to the second trailer
- Hydraulic locks on actuators protecting against uncontrolled opening of rear wall
- New 385/65 R22.5 wheels
- Axles from renowned ADR company, full beam with 100 mm square cross-section, 406 x 120 brake
- Parabolic leaf spring suspension
- Two wheel chocks placed in galvanized pockets
- Telescopic actuator, five-level, pitch 2,400 mm. Useful force at fifth level with diameter 140 mm, at
nominal pressure 20MPa = 307.9kN (31.4T) - Wheel fenders
Additional equipment
- Spare wheel winch with hot-galvanized wheel hanger
- Hot-galvanized tarpaulin frame made of 40x40x3 closed profi les **
- 500 mm wall extensions, thickness 2.5 mm
- Chute for precise tipping, hot-galvanized
- Hot-galvanized work platform
- Full LED lighting
- Surcharge for “new” 550/45 R22.5 wheels
- 385/65 R22.5 “new” spare wheel
- 550/45 R22.5 “new” spare wheel
- Surcharge for “new” 550/60 R22.5 wheels
- 550/60 R22.5 “new” spare wheel
- Turning axle – drawn
- Roll-up tarpaulin **
- Hydraulic quick-coupler with pressure neutralizer in hose
- Warning triangle (sign distinguishing slow-moving vehicle)
- K80 tension member (tolerable drawbar eye load increases to 4,000 kg)
- Drawbar eye 40mm
- Set of side (bicycle) guards
- Manual hitch for second trailer
- Water tank + soap dispenser***
- Toolbox***
** – available only with extensions
*** – it is not possible to simultaneously install the toolbox and water tank
