Wall height 500 mm with thickness 2.5 mm, hot-galvanized
Central bolt-locking of walls (bottom sideboards)
Exterior ladder and steps inside cargo box - hot-galvanized - with anti-skid steps facilitating access
to cargo box
to cargo box
Rigid drawbar for coupling with the top or bottom hitch of the tractor, with replaceable eye, drawbar
homologated according to Regulation 55UN ECE
homologated according to Regulation 55UN ECE
New 11.5/80-15.3 wheels
Axles from renowned ADR company, full beam with 70mm square cross-section, 300x60 brake
Technical data
- Administrative loading capacity ~3560 kg*
- Technical loading capacity ~3560 kg*
- Gross vehicle weight rating according to PL regulations 4,920 kg
- Gross vehicle weight rating according to Directive 2015/208
(only load on axles) 3,920 kg - Kerb weight (without wall extensions) ~ 1,360 kg
- Number of axles 1
- Length 4,710 mm
- Width 1,990 mm
- Height without extensions 1,560 mm
- Height with extensions 2,060 mm
- Length of cargo box interior 3,345 mm
- Width of cargo box interior front/rear 1,830 mm
- Height of box walls (without extensions) 500 mm
- Height of platform from base 1,060 mm
- Floor/wall sheet thickness 3 / 2.5 mm
- Loading surface 6.1 m2
* – unladen weight and loading capacity may differ depending on the trailer’s equipment
- Loading capacity – without extensions / with extensions 3.05 m3 (6.1 m3)
- Track of wheels 1,500 mm
- Suspension Rigid
- Max. Vertical drawbar eye load 1,000 kg
- Drawbar coupling height – min. 500 mm
- Drawbar coupling height – max. 830 mm
- Max. tolerable vertical load on axle 3,860 kg
- Tire size 11.5/80-15.3
- Design speed 30 km/h
- Minimum demand for tractor power 22.1 kW / 30 HP
- Tipping angle of the cargo box (backward / sideways) 45 / 50
- Tipping system: three-way
Downloads
Features and accessories
- Structural elements
- Wall height 500 mm with thickness 2.5 mm, hot-galvanized
- Central bolt-locking of walls (bottom sideboards)
- Exterior ladder and steps inside cargo box – hot-galvanized – with anti-skid steps facilitating access
to cargo box - Maintenance support of cargo box, hot-galvanized
- Rigid drawbar for coupling with the top or bottom hitch of the tractor, with replaceable eye, drawbar
homologated according to Regulation 55UN ECE - Bolted hitch tension member dia. 40
- Hot-galvanized frame of cargo box
- Main stringers of cargo box frame made of 160x60x4 closed profiles
- Galvanized cargo box floor made of single riveted and bolted sheet, thickness 3mm
- Hot-dip galvanized bottom frame (protection of the structure on the exterior and interior of profiles), stringers of the frame made of metallurgical 160 and 140 channel sections, additionally closed by 5 mm sheet
- Parking handbrake with crank
- Grain chute, hot-galvanized, with blockade in the rear wall
- Straight drawbar support with collapsible steel wheel, partially hot-galvanized
- Homologated, hot-galvanized bumper
- Installations
- Tipping installation protected against excessive box inclination by cut-off valve
- Lighting installation connector cable with 7PIN 12V plug
- 12V lighting, homologated, rear bulb lamps, LED perimeter lighting
- Hydraulic tipping installation of cargo box made of galvanized steel tubes and flexible hoses
- Hydraulic connectors to tractor, type ISO 7241-1 DN 12.5
- Homologated, pneumatic double-circuit brake system with manual braking force adjustment
- Driving system
- New 11.5/80-15.3 wheels
- Axles from renowned ADR company, full beam with 70mm square cross-section, 300×60 brake
- Other elements
- Two wheel chocks placed in galvanized pockets
- Telescopic actuator with articulated suspensions, four-level with 1,300 mm pitch. Useful force at
fourth level with diameter 105mm, at nominal pressure 16MPa = 138kN (~14T)
Additional equipment
- Structural elements
- Spare wheel hanger, hot-galvanized
- Hot-galvanized tarpaulin frame made of 40x40x3 closed profi les
- Hot-galvanized 500 mm wall extensions, thickness 2.5 mm
- Chute for precise tipping, hot-galvanized
- Hot-galvanized mesh wall extensions, height 1 000 mm
- Installations
- Full LED lighting
- Homologated, hydraulic double-circuit brake system with manual braking force adjustment
- Overrun braking system
- Driving system
- 11.5/80-15.3 spare wheel
- Other equipment
- Laced tarpaulin
- Hydraulic quick-coupler with pressure neutralizer in hose
- Warning triangle (sign distinguishing slow-moving vehicle)
- DUPLEX – painted set of walls
- DUPLEX – painted set of extensions
