Hot-dip galvanised drawbar
Hot-dip galvanised adapter cover
New wheels 23x8.5-12
Technical data
- Technical loading capacity 800 kg
- Gross vehicle weight rating according to PL regulations 1320 kg
- Unladen mass ~ 520 kg
- Number of axles 1
- Adapter A2H – 2 horizontal shafts
- Length 3,020 mm
- Width 1,400 mm
- Height Transport/
working speed 1100 / 1730 mm - Length of loading space ext. (góra) 1,560 mm
- Width of loading box interior 700 mm
- Height of loading box walls 520 mm
- Height of platform from base 480 mm
- Loading height 990 mm
- Floor/wall sheet thickness 3 / 3 mm
- Conveyor drive Mechanical, with road
wheel - Adapter drive Mechanical, with road
wheel - Openable side walls No
- Loading capacity (loading 5cm above the side walls): 0.6 m3
- Track of wheels 1,170 mm
- Suspension rigid axle
- Drawbar eye load 120 kg
- Max. drawbar eye load 120 kg
- Drawbar coupling height – bottom position 350 mm
- Max. tolerable axle load 1,200 kg
- Tyre size 23×8.5-12
- Design speed 15 km/h
- Minimum demand for tractor power 14.7kW/20KM
- Spreading width depending on manure used ~1 m
Downloads
Features and accessories
- Wall height 520 mm – hot-dip galvanised
- A2H blade adapter powered by driving wheels
- Galvanised sheet metal floor
- Hot-dip galvanised drawbar
- Conveyor and adapter drive from spreader wheels. Conveyor drive with
- adjustable feed speed.
- The rear wall in front of the adapter is hot-dip galvanised
- Hot-dip galvanised adapter cover
- Adapter cover folded over the front of the spreader to protect the operator
- Ball hitch k50
- Construction
- Collapsible drawbar support with rubber-coated wheel
- Hot-dip galvanised conveyor chain
- Replaceable hot-dip galvanised conveyor slats
- New wheels 23×8.5-12
- Differential for easy manoeuvering
Additional equipment
- Eye hitch 40mm or 50mm
- Warning triangle
